Nominal Diameter | Outside Diameter | Center to End | ||||
---|---|---|---|---|---|---|
D1 | D2 | |||||
DN | NPS | Series A | Series A | "C" | "M" | |
(Inches) | (mm) | (mm) | (mm) | (mm) | ||
15×15×15 |
1/2 × 1/2 ×1/2 |
21.3 |
21.3 |
25 |
25 |
|
15×15×10 |
1/2×1/2×3/8 |
21.3 |
17.3 |
25 |
25 |
|
15×15×8 |
1/2×1/2×1/4 |
21.3 |
13.7 |
25 |
25 |
|
20×20×20 |
3/4×3/4×3/4 |
26.9 |
26.9 |
29 |
29 |
|
20×20×15 |
3/4×3/4×1/2 |
26.9 |
21.3 |
29 |
29 |
|
20×20×10 |
3/4×3/4×3/8 |
26.9 |
17.3 |
29 |
29 |
|
25×25×25 |
1×1×1 |
33.7 |
33.7 |
38 |
38 |
|
25×25×20 |
1×1×3/4 |
33.7 |
26.9 |
38 |
38 |
|
25×25×15 |
1×1×1/2 |
33.7 |
21.3 |
38 |
38 |
|
32×32×32 |
1.1/4×1.1/4×1.1/4 |
42.4 |
42.4 |
48 |
48 |
|
32×32×25 |
1.1/4×1.1/4×1 |
42.4 |
33.7 |
48 |
48 |
|
32×32×20 |
1.1/4×1.1/4×3/4 |
42.4 |
26.9 |
48 |
48 |
|
32×32×15 |
1.1/4×1.1/4×1/2 |
42.4 |
21.3 |
48 |
48 |
|
40×40×40 |
1.1/2×1.1/2×1.1/2 |
48.3 |
48.3 |
57 |
57 |
|
40×40×32 |
1.1/2×1.1/2×1.1/4 |
48.3 |
42.4 |
57 |
57 |
|
40×40×25 |
1.1/2×1.1/2×1 |
48.3 |
33.7 |
57 |
57 |
|
40×40×20 |
1.1/2×1.1/2×3/4 |
48.3 |
26.9 |
57 |
57 |
|
40×40×15 |
1.1/2×1.1/2×1/2 |
48.3 |
21.3 |
57 |
57 |
|
50×50×50 |
2×2×2 |
60.3 |
60.3 |
64 |
64 |
|
50×50×40 |
2×2×1.1/2 |
60.3 |
48.3 |
64 |
60 |
|
50×50×32 |
2×2×1.1/4 |
60.3 |
42.4 |
64 |
57 |
|
50×50×25 |
2×2×1 |
60.3 |
33.7 |
64 |
51 |
|
50×50×20 |
2×2×3/4 |
60.3 |
26.9 |
64 |
44 |
|
65×65×65 |
2.1/2×2/1/2×2.1/2 |
73 |
73 |
76 |
76 |
|
65×65×50 |
2.1/2×2/1/2×2 |
73 |
60.3 |
76 |
70 |
|
65×65×40 |
2.1/2×2/1/2×1.1/2 |
73 |
48.3 |
76 |
67 |
|
65×65×32 |
2.1/2×2/1/2×1.1/4 |
73 |
42.4 |
76 |
64 |
|
65×65×25 |
2.1/2×2/1/2×1 |
73 |
33.7 |
76 |
57 |
|
80×80×80 |
3×3×3 |
88.9 |
88.9 |
86 |
86 |
|
80×80×65 |
3×3×2.1/2 |
88.9 |
73 |
86 |
83 |
|
80×80×50 |
3×3×2 |
88.9 |
60.3 |
86 |
76 |
|
80×80×40 |
3×3×1.1/2 |
88.9 |
48.3 |
86 |
73 |
|
80×80×32 |
3×3×1.1/4 |
88.9 |
42.4 |
86 |
70 |
|
90×90×90 |
3.1/2×3.1/2×3.1/2 |
101.6 |
101.6 |
95 |
95 |
|
90×90×80 |
3.1/2×3.1/2×3 |
101.6 |
88.9 |
95 |
92 |
|
90×90×65 |
3.1/2×3.1/2×2.1/2 |
101.6 |
73 |
95 |
89 |
|
90×90×50 |
3.1/2×3.1/2×2 |
101.6 |
60.3 |
95 |
83 |
|
90×90×40 |
3.1/2×3.1/2×1.1/2 |
101.6 |
48.3 |
95 |
79 |
|
100×100×100 |
4×4×4 |
114.3 |
114.3 |
105 |
105 |
|
100×100×90 |
4×4×3.1/2 |
114.3 |
101.6 |
105 |
102 |
|
100×100×80 |
4×4×3 |
114.3 |
88.9 |
105 |
98 |
|
100×100×65 |
4×4×2.1/2 |
114.3 |
73 |
105 |
95 |
|
100×100×50 |
4×4×2 |
114.3 |
60.3 |
105 |
89 |
|
100×100×40 |
4×4×1.1/2 |
114.3 |
48.3 |
105 |
86 |
|
125×125×125 |
5×5×5 |
141.3 |
141.3 |
124 |
124 |
|
125×125×100 |
5×5×4 |
141.3 |
114.3 |
124 |
117 |
|
125×125×90 |
5×5×3.1/2 |
141.3 |
101.6 |
124 |
114 |
|
125×125×80 |
5×5×3 |
141.3 |
88.9 |
124 |
111 |
|
125×125×65 |
5×5×2.1.2 |
141.3 |
73 |
124 |
108 |
|
125×125×50 |
5×5×2 |
141.3 |
60.3 |
124 |
105 |
|
150×150×150 |
6×6×6 |
168.3 |
168.3 |
143 |
143 |
|
150×150×125 |
6×6×5 |
168.3 |
141.3 |
143 |
137 |
|
150×150×100 |
6×6×4 |
168.3 |
114.3 |
143 |
130 |
|
150×150×90 |
6×6×3.1/2 |
168.3 |
101.6 |
143 |
127 |
|
150×150×80 |
6×6×3 |
168.3 |
88.9 |
143 |
124 |
|
150×150×65 |
6×6×2.1/2 |
168.3 |
73 |
143 |
121 |
|
200×200×200 |
8×8×8 |
219.1 |
219.1 |
178 |
178 |
|
200×200×150 |
8×8×6 |
219.1 |
168.3 |
178 |
168 |
|
200×200×125 |
8×8×5 |
219.1 |
141.4 |
178 |
162 |
|
200×200×100 |
8×8×4 |
219.1 |
114.3 |
178 |
156 |
|
200×200×90 |
8×8×3.1/2 |
219.1 |
101.6 |
178 |
152 |
|
250×250×250 |
10×10×10 |
273 |
273 |
216 |
216 |
|
250×250×200 |
10×10×8 |
273 |
219.1 |
216 |
203 |
|
250×250×150 |
10×10×6 |
273 |
168.3 |
216 |
194 |
|
250×250×125 |
10×10×5 |
273 |
141.3 |
216 |
191 |
|
250×250×100 |
10×10×4 |
273 |
114.3 |
216 |
184 |
|
300×300×300 |
12×12×12 |
323.9 |
323.9 |
254 |
254 |
|
300×300×250 |
12×12×10 |
323.9 |
273 |
254 |
241 |
|
300×300×200 |
12×12×8 |
323.9 |
219.1 |
254 |
229 |
|
300×300×150 |
12×12×6 |
323.9 |
168.3 |
254 |
219 |
|
300×300×125 |
12×12×5 |
323.9 |
141.3 |
254 |
216 |
|
350×350×350 |
14×14×14 |
355.6 |
355.6 |
279 |
279 |
|
350×350×300 |
14×14×12 |
355.6 |
323.9 |
279 |
270 |
|
350×350×250 |
14×14×10 |
355.6 |
273 |
279 |
257 |
|
350×350×200 |
14×14×8 |
355.6 |
219.1 |
279 |
248 |
|
350×350×150 |
14×14×6 |
355.6 |
168.3 |
279 |
238 |
|
400×400×400 |
16×16×16 |
406.4 |
406.4 |
305 |
305 |
|
400×400×350 |
16×16×14 |
406.4 |
355.6 |
305 |
305 |
|
400×400×300 |
16×16×12 |
406.4 |
323.9 |
305 |
295 |
|
400×400×250 |
16×16×10 |
406.4 |
273 |
305 |
283 |
|
400×400×200 |
16×16×8 |
406.4 |
219.1 |
305 |
273 |
|
400×400×150 |
16×16×6 |
406.4 |
168.3 |
305 |
264 |
